Inputs/Outputs:

System Connection:

USB-B 3.0 / 3.1/3.2 Gen 1

Video Inputs:

1x HDMI (1.4a)

Audio Inputs:

No

Format Support:

Input Video Format:

HDMI

480i / 525 lines at 29.97/59.94 fps

576i / 625 lines at 25/50 fps

720p at 50/59.94/60 fps

1080i at 50/59.94/60 fps

1080p at 23.98/24/25/29.97/30/50/59.94/60 fps

Input Audio Format:

S/PDIF: 48 kHz / 24-Bit

Output Video Format:

USB-B

1080p at 7.5/15/25/29.97/30/50/59.94/60 fps

720p at 7.5/15/25/29.97/30/50/59.94/60 fps

1024 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps

1440 x 1080 at 7.5/15/25/29.97/30/50/59.94/60 fps

960 x 540 at 7.5/15/25/29.97/30/50/59.94/60 fps

856 x 480 at 7.5/15/25/29.97/30/50/59.94/60 fps

SVGA (800 x 600) at 7.5/15/25/29.97/30/50/59.94/60 fps

768 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps

720 x 576 at 7.5/15/25/29.97/30/50/59.94/60 fps

720 x 480 at 7.5/15/25/29.97/30/50/59.94/60 fps

VGA (640 x 480) at 7.5/15/25/29.97/30/50/59.94/60 fps

640 x 360 at 7.5/15/25/29.97/30/50/59.94/60 fps

432 x 240 at 7.5/15/25/29.97/30/50/59.94/60 fps

352 x 288 at 7.5/15/25/29.97/30/50/59.94/60 fps

QVGA (320 x 240) at 7.5/15/25/29.97/30/50/59.94/60 fps

176 x 144 at 7.5/15/25/29.97/30/50/59.94/60 fps

Output Audio Format:

S/PDIF: 48 kHz / 16-Bit

Embedded Audio:

HDMI: 2-Channel

Standards:

HDCP Support:

No

Hardware:

Tally Light:

Yes

OS Compatibility:

Windows 11

macOS 12.3

Linux 20

Power:

Power I/O:

1x USB-B Input

Environmental:

Operating Temperature:

32 to 104°F / 0 to 40°C

Storage Temperature:

-40 to 140°F / -40 to 60°C

Operating Humidity:

10 to 90%

General:

Certifications:

BSMI CNS 13438 Class A, CE, FCC Part 15 Class A, FCC, ICES, VCCI Class A

Dimensions:

3.3 x 2.4 x 1" / 83.82 x 60.96 x 25.4 mm

Weight:

0.3 lbs
