Key Specs:

Display Size:

19.00" / 48.3 cm

Native Resolution:

1920 x 1080

Touchscreen:

Yes

HDR Support:

Yes: Hybrid Log Gamma

Video I/O:

1 x HDMI 2.0 Input

1 x HDMI 2.0 Output

2 x BNC (12G-SDI) Input

2 x BNC (3G-SDI) Input

1 x BNC (12G-SDI) Loop Output

Media/Memory Card Slot:

Single Slot: SSDmini/SSD with Master Caddy II/III [Supports Recording]

Video Format:

HDMI/SDI (10-Bit 4:2:2)

DCI 4K: 60

UHD 4K: 60

Phantom Power:

+48 V

Battery:

Interchangeable Mount (No Plate Included)

Power Consumption:

75 W

Display:

Panel Type:

IPS-Type LCD

Display Size:

19.00" / 48.3 cm

Native Resolution:

1920 x 1080

Aspect Ratio:

16:9

Touchscreen:

Yes

Maximum Brightness:

1200 nits / cd/m2

Color Support:

1.07 Billion Colors (8-Bit+FRC)

HDR Support:

Yes: Hybrid Log Gamma

Color Gamut:

100% DCI-P3

LUT Support:

Yes

Image Controls:

Anamorphic De-Squeeze, False Color, Focus Peaking, OSD Flip, Pixel Zoom, RGB Parade, Vectorscope, Waveform, Zebra

Inputs/Outputs:

Video I/O:

1 x HDMI 2.0 Input

1 x HDMI 2.0 Output

2 x BNC (12G-SDI) Input

2 x BNC (3G-SDI) Input

1 x BNC (12G-SDI) Loop Output

Embedded Audio:

HDMI: 8-Channel

SDI: 12-Channel

Audio I/O:

2x XLR Input

2x XLR Output

1x 1/8" / 3.5 mm Headphone Output

Built-In Speaker:

Stereo

Power I/O:

2x XLR 4-Pin (14.4 VDC) Input

1x XLR 4-Pin (16.8 VDC) Input

Other I/O:

1x BNC (Genlock) Input

1x 2.5 mm (LANC) Input

Media/Memory Card Slot:

Single Slot: SSDmini/SSD with Master Caddy II/III [Supports Recording]

Wireless

Wi-Fi:

No

Bluetooth:

No

Mobile App Compatible:

No

Format Support:

Video Format:

HDMI/SDI (10-Bit 4:2:2)

DCI 4K: 60

UHD 4K: 60

Video Signal Conversion:

HDMI to SDI

SDI to HDMI:

Timecode Support:

Yes

Recording:

Pulldown Conversion:

2:2, 3:2

Camera Trigger:

SDI, HDMI

Pre-Roll Record:

Full HD: 8 Seconds

4K: 2 Seconds

Encoding Formats:

x

ProRes Raw

ProRes 422 HQ 10-Bit

DNxHR 422 HQ 10-Bit

Closed Caption Support:

No

Reference Input:

No

Phantom Power:

+48 V

Power:

Input Power:

12 to 16.8 VDC

Battery:

Interchangeable Mount (No Plate Included)

Power Consumption:

75 W

Mounting:

VESA Mounting-Hole Pattern:

100 x 100 mm

Tripod/Accessory Mounting:

10x 1/4"-20 Female

5x 3/8"-16 Female

General:

Material of Construction:

Aluminum, Polycarbonate

Dimensions:

19.8 x 13 x 7.1" / 504 x 330 x 180 mm (Including Feet)

19.8 x 12.2 x 2.5" / 504 x 310 x 63 mm (Excluding Feet)

Weight:

12.02 lbs
