Inputs/Outputs:

Video Inputs:

1x BNC (12G-SDI) Female

1x HDMI (2.0) Female

Video Outputs:

1x BNC (12G-SDI) Female

1x HDMI (2.0) Female

Other I/O:

1x USB-C Firmware Input (Shared Power)

Format Support:

Input Video Format:

SDI (8/10-Bit 4:2:2 RGB, YUV)

DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

DCI 2KPsF at 25/29.97/30 fps

1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080PsF at 25/29.97/30 fps

1080i at 50/59.94/60 fps

720p at 50/59.94/60 fps

576i / 625 lines at 50 fps

480i / 525 lines at 59.94 fps

HDMI (8/10-Bit 4:2:2 RGB, YUV)

DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080i at 50/59.94/60 fps

720p at 50/59.94/60 fps

576i / 625 lines at 50 fps

480i / 525 lines at 59.94 fps

Output Video Format:

SDI (8/10-Bit 4:2:2 RGB, YUV)

DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

DCI 2KPsF at 25/29.97/30 fps

1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080PsF at 25/29.97/30 fps

1080i at 50/59.94/60 fps

720p at 50/59.94/60 fps

480i / 525 lines at 29.97 fps

576i / 625 lines at 25 fps

HDMI (8/10-Bit 4:2:2 RGB, YUV)

DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps

1080i at 50/59.94/60 fps

720p at 50/59.94/60 fps

576i / 625 lines at 50 fps

480i / 525 lines at 59.94 fps

Embedded Audio:

HDMI/SDI

Standards:

Video Standard Compliance:

SMPTE 259M/292M/296M/424M/425M-A/425M-B

HDCP Support:

Version 2.2

HDMI CEC:

Yes

Hardware:

Tally Light:

Yes

Wireless:

No

OS Compatibility:

macOS 10.15.15 or Later

Windows 11.1 or Later

Power:

Power I/O:

1x USB-C (4.4 to 5.2 VDC ) Input

Power Consumption:

Device: 5 W

Environmental:

Operating Temperature:

32 to 72°F / 0 to 40°C

Storage Temperature:

-4 to 140°F / -20 to 60°C

Operating Humidity:

0 to 90%

General:

Dimensions:

3.18 x 2.32 x 0.98" / 80.77 x 58.93 x 24.89 mm

Weight:

0.38lb
