Key Specs:

Inputs:

16 x BNC (3G-SDI / 6G-SDI / HD-SDI)

Embedded Audio:

SDI

Outputs:

16x BNC (6G-SDI / HD-SDI / SD-SDI, Looping)

2x BNC (6G-SDI)

2x BNC (HD-SDI)

1x HDMI

Video Format:

SDI (10-Bit 4:2:2 RGB, YUV)

DCI 4K: 24 fps

UHD 4K: 23.98/24/25/29.97/30 fps

DCI 2KPsF: 23.98/24/25 fps

DCI 2K: 23.98/24/25 fps

1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1080PsF: 23.98/24/25/29.97/30 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

NTSC: 59.94 fps

PAL: 50 fps

Interfaces:

Inputs:

16 x BNC (3G-SDI / 6G-SDI / HD-SDI)

Embedded Audio:

SDI

Outputs:

16x BNC (6G-SDI / HD-SDI / SD-SDI, Looping)

2x BNC (6G-SDI)

2x BNC (HD-SDI)

1x HDMI

Other I/O:

1x RJ45 (RS-422)

1x RJ45 (10/100 Mbps Ethernet)

1x Mini-USB 2.0

Standards:

Video Standard Compliance:

SMPTE 259M/292M/296M/425M-B

ITU -R BT.601/BT.656

Reclocking:

Yes

HDR Support:

No

HDCP Support:

Yes

EDID Support:

Yes

OS Compatibility:

macOS 10.15 to 11.1 or Later

Windows 10 (64-Bit Only)

Transmission:

Video Format:

SDI (10-Bit 4:2:2 RGB, YUV)

DCI 4K: 24 fps

UHD 4K: 23.98/24/25/29.97/30 fps

DCI 2KPsF: 23.98/24/25 fps

DCI 2K: 23.98/24/25 fps

1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

1080PsF: 23.98/24/25/29.97/30 fps

1080i: 50/59.94/60 fps

720p: 50/59.94/60 fps

NTSC: 59.94 fps

PAL: 50 fps

Maximum Multiple Display Configuration:

4 x 4

Maximum Sampling Rate:

48 kHz / 24-Bit

Maximum Data Rate:

6 Gb/s

Power:

Power I/O:

1x IEC C14 Input

Power Consumption:

90 to 240 VAC (45 W)

General:

Rack Form Factor:

1 U

Certifications:

FCC Class A

Operating Conditions:

32 to 104°F / 0 to 40°C up to 90% Humidity

Storage Conditions:

-4 to 113°F / -20 to 45°C

Material of Construction:

Metal

Dimensions:

19.0 x 6.0 x 1.7" / 482.6 x 152.4 x 43.2 mm

Weight:

5.07 lbs.
