I/O:

1 x SD/HD/3G-SDI BNC input

1 x SD/HD/3G-SDI BNC loop output

1 x HDMI type A output

1 x USB Micro-B

Format Support:

1080p24/25/29.97/30/50/59.94

1080PsF25/29.97/30

1080i50/59.94/60

720p50/59.94/60

NTSC

PAL

SDI Compliance:

SMPTE 259M

SMPTE 292M

SMPTE 296M

SMPTE 372M

SMPTE 425M

Color Precision:

4:2:2

Color Space:

YUV and RGB

OS Support:

Mac OS X 10.10, 10.11 or later

Windows 8.1, 10

Power:

Power Input:

5 VDC via USB Micro-B

Power Consumption:

1.6 W

Operational Voltage Range:

4.4 to 5.25 VDC

EnvironmentalOperating Temperature:

32 to 104°F / 0 to 40°C

Storage temperature:

-4 to 140°F / -20 to 60°C

Relative humidity:

0 to 90% non-condensing

Dimensions:

3 x 1.8 x 1" / 76 x 46 x 25 mm

Weight:
0.33lbs.
