Input:

1x HDMI

1x BNC (3G-SDI)



Output:

1x HDMI

2x BNC (3G-SDI)

 2x BNC (3G-SDI) (Loop Output)

Video Resolution:



SDI Input:

1920 x 1080p up to 59.94 fps

1920 x 1080PsF up to 29.97 fps

1920 x 1080i up to 59.94 fps

1280 x 720 up to 59.94 fps

768 x 576i at 50 fps

640 x 480i at 59.94 fps



SDI Output:

1920 x 1080p up to 59.94 fps

1920 x 1080PsF up to 29.97 fps

1920 x 1080i up to 59.94 fps

1280 x 720 up to 59.94 fps

768 x 576i at 50 fps

640 x 480i at 59.94 fps



Embedded Audio:

HDMI/SDI





Video Standard Compliance:

SMPTE: 259M/274M/292M/296M/424M



Broadcast System Compatibility:

NTSC, PAL

Power I/O:

1x Barrel (5 to 32 VDC ) Input

Dimensions:

4.8 x 3.1 x 1.2" / 123 x 79.5 x 29.5 mm

Weight:

1.7 lbs
