SDI Formats:

3G-A or 3G-B:SMPTE 424M@2.97 and 2.967Gb/s

1080p@60/59.94/50Hz

1080i@60/59.94/50Hz

1080p/psf@30/29.97/25/24/23.98Hz

720p@60/59.94/50/30/29.97/25/24/23.98Hz SD:SMPTE 259M@270Mb/s

625i50 (PAL)

525i59.94 (NTSC)



HDMI Formats:

1080p@60/59.94/50/30/29.97/25/24/23.98Hz

1080i@60/59.94/50Hz

720p@60/59.94/50/30/29.97/25

625i50 (PAL)

525i59.94 (NTSC)



INPUTS:

1x HDMI Type A

1x (3G/HD/SD)-SDI

1x Micro USB for power, control and firmware updates



Outputs:

1x HDMI Type A

1x (3G/HD/SD)-SDI



Power:

USB Power +4.4V to +5.25V DC

Uses under 2.5 Watts



DIMENSIONS:

 60mm x 73.7mm x 23mm (2.4” x 2.9” x 0.9”)
