Overview:

Connectivity:

USB Type-C

Protocol:

USB 2.0

Form Factor:

Rack Mount (1U)

Simultaneous I/O:

18 x 20

A/D Resolution:

24-bit/192 kHz

Number of Preamps:

8

Phantom Power:

Yes

Number of Pads:

8

Instrument Inputs:

2

Line Inputs:

8

Analogue Outputs:

10

Headphone Outputs:

2

Main/Alt Speaker Switching:

Yes

Talkback:

Yes

Digital Inputs:

S/PDIF and 2 x ADAT

Digital Outputs:

S/PDIF and 2 x ADAT

Loopback:

Yes

MIDI I/O:

Yes

Bus Powered:

No

Included PSU:

Yes

Supported Sample Rates:

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone Inputs:

Frequency Response:

20Hz - 20kHz ± 0.1dB

Dynamic Range:

111dB (A-weighted)

THD+N:

<0.0012%

Noise EIN:

-128dBu (A-weighted)

Maximum Input Level:

9dBu (At Minimum Gain)

Gain Range:

56dB

Impedance:

3kΩ

Line Inputs:

Frequency Response:

20Hz - 20kHz ± 0.1dB

Dynamic Range:

110.5dB (A-weighted)

THD+N:

<0.002%

Maximum Input Level:

22dBu (At Minimum Gain)

Gain Range:

56dB

Impedance:

60kΩ

Instrument Inputs:

Frequency Response:

20Hz - 20kHz ± 0.1dB

Dynamic Range:

110dB (A-weighted)

THD+N:

<0.03%

Noise EIN:

12.5dBu (At Minimum Gain)

Maximum Input Level:

9dBu (at minimum gain)

Gain Range:

56dB

Impedance:

1.5MΩ

Line/Monitor Outputs:

Dynamic Range (Line Outputs):

108dB

THD+N:

<0.002%

Maximum output level (0 dBFS):

15.5dBu

Impedance:

430Ω

Headphone Outputs:

Dynamic Range:

104dB (A-weighted)

THD+N:

<0.002%

Maximum Output Level:

7dBu

Impedance:

<1Ω



Weight:

7.2lbs.
