Configuration

Inputs

6: analogue (4), S/PDIF (2)

Outputs

6: analogue (4), S/PDIF (2)

Mixer

Fully assignable 6-in/12-out software mixer

Digital Performance

Supported sample rates

44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz and 192 kHz

Clock jitter

<250 ps

Microphone Inputs

Frequency Response

20 Hz to 20 kHz, +0.5/-1.5 dB

Dynamic Range

109 dB (‘A’-weighted)

THD+N

< 0.002%

Noise EIN

–127 dBu

Maximum Input Level

+8.5 dBu (without pad)

Gain Range

50 dB

Line Inputs 1 & 2

Frequency Response

20 Hz to 20 kHz, +0.5/-1.5 dB

Dynamic Range

109 dB (‘A’-weighted)

THD+N

< 0.003%

Maximum Input Level

+22 dB

Gain Range

50 dB

Line Inputs 3 & 4

Frequency Response

20 Hz to 20 kHz, +0.5/-1.5 dB

Dynamic Range

109 dB (‘A’-weighted)

THD+N

< 0.003%

Maximum Input Level

+16 dB

Instrument Inputs

Frequency Response

20 Hz to 20 kHz, +0.5/-1.5 dB

Dynamic Range

109 dB (‘A’-weighted)

THD+N

< 0.003%

Maximum Input Level

+12 dBu

Gain Range

50 dB

Line Outputs 1 to 4

Frequency Response

20 Hz to 20 kHz, +/-0.5 dB

Dynamic Range

108 dB (‘A’-weighted)

THD+N

< 0.001%

Maximum Output Level (0 dBFS)

+16 dBu, balanced

Headphone Outputs

Frequency Response

20 Hz to 20 kHz, +/-0.5 dB

Dynamic Range

108 dB (‘A’-weighted)

THD+N

< 0.001%

Maximum Output Level (0 dBFS)

+13 dBu, balanced



Weight

2.58lb
