Overview

Connectivity

USB type-C

Protocol

USB 2.0

Form factor

Desktop

Simultaneous I/O

8 x 6

A/D resolution

24-bit/192 kHz

Number of preamps

2

Phantom power

Yes

Number of pads

2

Instrument inputs

2

Line inputs

6

Analogue outputs

4

Headphone outputs

2

Digital inputs

S/PDIF

Digital outputs

S/PDIF

Loopback

Yes

MIDI I/O

Yes

Bus powered

No

Included PSU

Yes

Supported sample rates

44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Microphone inputs

Frequency response

20Hz - 20kHz ± 0.1dB

Dynamic range

111dB (A-weighted)

THD+N

<0.0012%

Noise EIN

-128dBu (A-weighted)

Maximum input level

9dBu (at minimum gain)

Gain range

56dB

Impedance

3kΩ

Variable line inputs 1-2

Frequency response

20Hz - 20kHz ± 0.1dB

Dynamic range

110.5dB (A-weighted)

THD+N

<0.002%

Maximum input level

22dBu (at minimum gain)

Gain range

56dB

Impedance

60kΩ

Fixed line inputs 3-6

Frequency Response

20Hz - 20kHz ± 0.1dB

Dynamic Range

110.5dB (A-weighted)

THD+N

<0.002%

Maximum Input Level

18dBu

Impedance

44kΩ

Instrument inputs

Frequency Response

20Hz - 20kHz ± 0.1dB

Dynamic Range

110dB (A-weighted)

THD+N

<0.03%

Maximum Input Level

12.5dBu (at minimum gain)

Gain Range

56dB

Impedance

1.5MΩ

Line/monitor outputs

Dynamic range (line outputs)

108dB

THD+N

<0.002%

Maximum output level (0 dBFS)

15.5dBu

Impedance

430Ω

Headphone outputs

Dynamic range

104dB (A-weighted)

THD+N

<0.002%

Maximum output level

7dBu

Impedance

<1Ω



Weight

3.3lb
