Formats:

4K 12G-SDI, Ultra 4K 6G-SDI, 3G-SDI, 1.5G-SDI, 270Mb-SDI.

Meets and exceeds SMPTE-424, SMPTE-292, SMPTE-259

Inputs:

1x12G/ 6G/ 3G/ 1.5G/ 270Mb - Auto-selectable SDI, 1xBNC

Outputs:

4x12G/ 6G/ 3G/ 1.5G/ 270Mb, equalization and re-clocking

Cable Re-clocking and Equalization:

(all with Belden 1694A - divide by half for Belden 1505):

75 meters (246ft) at 12G, 100 meters (328ft) at 6G

220 meters (722ft) at 3G, 265 meters (870ft) at HD

530 meters (1740ft) at SD

Input return loss:

-8dB at 12G

-9dB at 6G

-13dB at 3G

-18dB HD/SD

Output return loss:

Return loss -6dB at 12G

-8.5dB at 6G

-15dB at 3G

-23dB at HD/SD
