Supported OS:
Windows:
7/8/8.1/10/2008/2008 R2/2012 (x86 & x64)
Linux:
(Ubuntu 12.04-16.10, CentOS 7)
OS X:
10.9-10.11
macOS:
10.12
Chrome OS
Supported APIs:
Windows:
DirectShow
Wave API/DirectSound/WASAPI
Linux:
V4L2
ALSA
OS X/macOS:
QuickTime
AV Foundation
Supported Software:
VLC
VirtualDub
OBS
XSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any Other DirectShow, V4L2, QuickTime, AV Foundation Based Encoding, or Streaming Software
Input Interface:
SD/HD/3G-SDI: 1 x BNC
Unbalanced Line-In: 3.5 mm Jack
Output Interface:
Loop-Through: 1 x BNC
Unbalanced Line-Out: 3.5 mm Jack
Host Interface:
USB 3.0: Compatible with USB 2.0/3.1
Input:
Resolution:
Supports up to 2048 x 1080
SDI Specific Features:
Integrated Cable Equalizer Supporting Cable Lengths up to 459' / 140 Meters for 3G-SDI Signals
Support for SD/HD/3Ga/3Gb/3Ga-DL/3Gb-DS Standards
Support for 2K (2048×1080) Mode
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 Color Sampling
Support for 10/12-bit Color Depth
Support for extraction of SMPTE 352 Payload Identifier
Support for up to 2 (Mono) Audio Channels at 48 kHz
Support for Extraction of Audio Formation Information & Channel Status Data
Limited Support of 3Gb-DS: Only the First Stream Can Be Captured
Limited Support for Capture of the First Link of Dual-Link Interfaces:
YCbCr 4:2:2 10-Bit 1080p 50/59.94/60: Captured as 1080i 50/59.94/60
YCbCr 4:4:4 10-Bit: Captured as 4:2:2
RGB 4:4:4: R/B Sub-Sampled
Analog Audio:
Extract the Embedded SDI Audio and Output via 3.5 mm Unbalanced Line Out
Capture Analog Audio via 3.5 mm Unbalanced Line-In Interface
Video Capture Format:
Support for Capture Resolutions up to 2048×1080
Support for Capture Frame Rates up to 120 fps (Actual Capture Frame Rate Can Be Limited by the USB Bandwidth and Internal Working Frequency. Typical Capture Frame Rates on the Intel USB 3.0 Controller are as Follows:)
1920×1080 YUY2 (up to 70 fps)
1920×1080 RGB24 (up to 60 fps)
Support for YUY2 & UYVY4:2:2 8-Bit
Support for RGB24 & RGB32 4:4:4 8-Bit
The Default Capture Format Is YUY2
More Capture Format Can Be Set Using USB Capture Utility
Power Consumption:
5 V Max Current: ~0.5 A
Max Power Consumption: ~2.5 W
Environment:
Operating Temperature: 32 to 122°F / 0 to 50°C
Storage Temperature: -4 to 158°F / -20 to 70°C
Relative Humidity: 5 to 90% Non-Condensing
Dimensions:
4.36 x 2.24 x 0.67" / 11.07 x 5.68 x 1.7 cm
Weight:
0.35lb
