Mono Inputs:

Mic inputs (MIDAS mic preamp)8

TypeXLR, balanced

Mic EIN @ 60 dB gain, 50 O source at insert send-131 dBu, unweighted, 20 Hz to 20 kHz

Mic EIN @ 60 dB gain, 150 O source at insert send-128 dBu, unweighted, 20 Hz to 20 kHz

Noise @ 10dB Gain, at insert send-97 dBu, unweighted, 20 Hz to 20 kHz

Frequency response (-1 dB) at main output20 Hz to 20 kHz (-1 dB)

Frequency response (-3 dB) at main output70 kHz (-3 dB)

Mic Gain range+10 dB to +60 dB

Max. input level+11 dBu @ +10 dB gain

CMRR @ +60dB gainTypically -90 dB

Impedance2 kO, balanced

Distortion (THD+N) at 0 dBu0.005% @ 1kHz

Phantom powerSwitchable, +48 V

Line Input:

Type  ¼" TRS, balanced

Impedance20 kO balanced / unbalanced

Line Gain range-10 dB to +40 dB

Max. input level+30 dBu

Stereo Inputs:

Type4 x ¼" TRS connector, balanced

Impedance20 kO balanced / unbalanced

Gain range-20 dB to +20 dB

Max. input level+21 dBu

Equaliser:

Low±15 dB @ 80 Hz, shelving

Mid (mono inputs only)±15 dB @ 150 Hz to 3.5 kHz, variable semi-parametric

High±15 dB @ 12 kHz, shelving

Channel Inserts:

Type   ¼" TRS connector, unbalanced

Max. input / output level+21 dBu

Aux Sends:

Type2 x ¼" TRS connector, balanced

Impedance240 O balanced, 120 O unbalanced

Max. output level+21 dBu

Monitor Out:

Type2 x ¼" TRS connector, balanced

Impedance240 O balanced, 120 O unbalanced

Max. output level+21 dBu

Main Out:

Type2 x XLR, electronically balanced

Impedance100 O balanced, 50 O unbalanced

Max. output level+21 dBu

Main Out Inserts:

Type2 x ¼" TRS connector, unbalanced

Max. input / output level+21 dBu

Phones Output:

Type¼" TRS connector, unbalanced

Impedance25 O

Max. output level+21 dBu

2-Track Input:

Type2 x RCA, unbalanced

Impedance20 kO

Max. input level+21 dBu

Record Out:

Type2 x RCA, unbalanced

Impedance1 kO

Max. output level+21 dBu

Main Mix System Noise:

Main mix @ -?, channel fader @ -8-104 dBu, unweighted, 20 Hz to 20 kHz

Main mix @ 0 dB, channel fader @ -8-91 dBu, unweighted, 20 Hz to 20 kHz

Main mix @ 0 dB, channel fader @ 0 dB-84 dBu, unweighted, 20 Hz to 20 kHz

Power Supply / Voltage (Fuses):

Switch mode power supply100-240 V~ 50/60 Hz, switchable (T 1.6 A H 250 V)

Power consumption40 W

Mains connectionStandard IEC receptacle

Dimensions / Weight:

Dimensions (H x W x D)95 x 328 x 370 mm (3.7 x 12.9 x 14.6")

Weight3.9 kg (1.8 lbs)
