Key Specs:

Display Size:

24.00" / 61.0 cm

Native Resolution:

3840 x 2160

Touchscreen:

Yes

HDR Support:

Yes

Video I/O:

2 x BNC (12G-SDI) Input

2 x BNC (3G-SDI) Input

1 x HDMI 1.4 Input

2 x BNC (12G-SDI) Output

2 x BNC (3G-SDI) Output

Media/Memory Card Slot:

No

Battery:

No

Display:

Panel Type:

TFT LCD

Display Size:

24.00" / 61.0 cm

Native Resolution:

3840 x 2160

Aspect Ratio:

16:9

Viewing Angle:

Horizontal: 178° (89/89)

Vertical: 178° (89/89)

Touchscreen:

Yes

Maximum Brightness:

1000 nits / cd/m2

Color Support:

1.07 Billion Colors (10-Bit)

HDR Support:

Yes

Inputs/Outputs:

Video I/O:

2 x BNC (12G-SDI) Input

2 x BNC (3G-SDI) Input

1 x HDMI 1.4 Input

2 x BNC (12G-SDI) Output

2 x BNC (3G-SDI) Output

Audio I/O:

1x 1/8" / 3.5 mm Monitor Output

1x 1/8" / 3.5 mm Headphone Output

Built-In Speaker:

Stereo

Power I/O:

1x XLR 3-Pin Input

Other I/O:

1x RJ45 (Parallel) Input

1x RJ45 (LAN) Input

Media/Memory Card Slot:

No

Wireless:

Wi-Fi:

No

Bluetooth:

No

Mobile App Compatible:

No

Power:

Input Power:

22 to 32 VDC

100 to 240 VAC, 50 / 60 Hz

Battery:

No

Mounting:

Rack Form Factor:

9 U

General:

Operating Conditions:

32 to 95°F / 0 to 35°C at 30 to 85% Humidity

Storage Conditions:

-4 to 140°F / -20 to 60°C



Dimensions:

22.4 x 15.9 x 7" / 56.8 x 40.4 x 17.9 cm

Weight:

23 lbs
