Specifications:

Receiver:

Receiver Channels:

1

Diversity method:

antenna switching

RF Modulation:

proprietary digital method

RF Frequency Range:

512 to 698 MHz

RF Frequency Step:

100 KHz

RF Signal Bandwidth:

200 KHz

Channel Separation:

500 KHz (700 KHz recommended)

Sensitivity:

-114 dBm

Antenna Connector:

50-ohm SMA female

Receiver Audio – Analog Output:

Dynamic Range:

110 dB

Distortion:

0.002%

Frequency Range:

20Hz to 16kHz

DAC Bit-depth:

24 bits

Connector:

TA-5M

Audio Output:

Impedance:

16 ohms

Output Power:

100 mW

Output Type:

Headphone driver

Output Connector:

3.5 mm

Mode:

2-Channel unbalanced or 1-Channel balanced

Max Output Level:

+12 dBm

Timecode:

Timecode Output Connector:

TA5 Male

Timecode Output Level:

.01VPP – 3VPP Variable

Time Code Output Rate:

23.98, 24, 25, 29.97 ND, 29.97 DF, 30

TA5 Auxiliary Connector:

Available Functions:

Timecode Output, Left Audio Out, Walkie Microphone Out, Walkie Audio Return

Power:

Internal Power:

3 AA Batteries

Li-Ion Battery Life:

Up to 11 hours

NiMH Battery Life:

Up to 9 hours

Alkaline Battery Life:

Up to 7 hours

Weight:

0.28lb Without Batteries

Dimensions:

4.1” x 2.5” x .9”

Display:

Graphic OLED Panel
