Audio Bandwidth:

200Hz-7.5KHz

No. of Full-Duplex Audio Paths:

Up to 5 with individual level control (2 dedicated rotaries, 3 with menu), 2 controls and a main volume

Mode of Operation:

Full duplex on all routes

Level/Talk Controls:

4 pushbuttons, a reply button and 2 rotary controls

Enter/Answer-Back Button:

1

Bluetooth® 4.3 Headset ProfileCodec:

MSBC using HFP (Hands Free Profile)

Frequency Spectrum:

USA, Canada, Mexico 1920-1930 MHz

Transceiver Range Output Power:

100mW

Headset Connector:

4-pin male, Clear-Com standard, options for 5-pin female and 7-pin male with PTT

Headset Voltage:

Maximum of ~+8dBu as set by firmware

Microphone Type:

Electret and Dynamic, selectable in beltpack menu

Microphone Voltage: Electret Mic:

-45dBu (additional 2.5V DC bias voltage positive on Pin 2 and negative on Pin 1 via a 1k resistor).

Dynamic Mic:

 -55dBu

Headset Limiter:

Selectable from beltpack menu

Modulation:

GFSK, TDMA frame 10ms Full and Long slot

Output Power:

(US) 18-20dBm

Range:

Typical indoor range 300ft (90m), outdoor range 800ft (240m)

Battery:

Li-Ion or 3 AA alkaline cells

Battery Charging:

Drop-in charger (AC60) or local USB

Battery Life:

18+ hours with Li-Ion; 9 hours with 3 x Alkaline AA cells

Environmental:

IP53 water and dust resistance

Operating:

32º-125ºF (0º-50ºC)

Storage:

32º-150ºF (0º-70ºC)

Humidity:

Between 20% and 90%, Non-Condensing

Dimensions:

Tapered design at largest points

3.75 x 5 x 1.5in (HxWxD)

(97 x 130 x 45mm)

Weight:

9.0oz (0.4kg) including batteries
